Evac Evolution BWMS On USCG ‘Pending List’

The Evac Evolution ballast water management system (BWMS), designed and manufactured by Cathelco, has been added to the pending list for U.S. Coast Guard Type Approval under the Cathelco name.

When Finnish-based Evac acquired Cathelco earlier this year, the latter were already well on the way to USCG Type Approval having completed all the stages of the land and sea-based testing programs. For this reason, the system appears on the pending list under Cathelco’s name.

With a turnover of 160 million euros in 2018, and offices in 14 countries across four continents, the Evac Group provides a backbone of financial stability and service in which customers can place their faith.

Based on a combination of filtration and UV technology, the Evac Evolution system has been tested in ‘real world’ conditions and technically enhanced over a 10 year period. “At an early stage, we opted for UV transmission as the parameter for determining UV dosage and I think it is only a matter of time before this becomes a mandatory requirement. In this sense, customers who buy an Evac Evolution system will already be ahead of the game”, said Robert Field, technical director of Cathelco.

Based on a combination of filtration and UV technology, the system is available with capacities from 34 m3/h to 1,500 m3/h in a single unit. The equipment can be provided skid mounted or in modular form, simplifying retrofit installations in confined areas.

A unique feature of the system is a feedback ‘loop’ which ensures thorough irradiation of organisms, whilst ensuring that power is used as economically possible.

The Cathelco UV transmission sensor system ensures precise UV dosage by adjusting the UV level to different water qualities. It is achieved by taking a sample of sea water before it reaches the UV chambers and measuring the amount of UV light actually passing through it. This works in conjunction with UV intensity meters which are mounted on the chamber and measure the intensity of light which is received.

The system has already been supplied for vessels ranging from luxury cruise ships and super yachts to container ships, ro-ro vessels, bunkering tankers, offshore supply vessels and Arctic fishing craft.
